CARACTERÍSTICAS:
- Resolución: 0.01mm/0.0005″.
- Botones: on/off, zero, mm/inch.
- Auto-Apagado, al deslizar la unidad se auto-enciende el equipo.
- Batería CR2032.
- Fabricado en acero inoxidable.
- Suministrado con certificado de inspección trazable a DKD Alemán.
ESPECIFICACIONES:
Con salida de datos
|
CÓDIGO |
RANGO | PRECISIÓN | L | a | b | c | d |
CABLE SALIDA DATOS (OPCIONAL) |
| 1142-150A |
0-150mm/0-6” |
±0.03mm | 230mm | 5mm | 2mm | 14.5mm | 100mm |
7315-21, 7302-21 |
| 1142-200A |
0-200mm/0-8” |
±0.03mm | 280mm | 5mm | 2mm | 14.5mm | 100mm |
7315-21, 7302-21 |
| 1142-300A |
0-300mm/0-12” |
±0.04mm | 380mm | 5mm | 2mm | 14.5mm | 150mm |
7315-21, 7302-21 |
| 1142-500A |
0-500mm/0-20” |
±0.05mm | 585mm | 8mm | 3mm | 15mm | 150mm |
7315-21, 7302-21 |
| 1142-5001A |
0-500mm/0-20” |
±0.05mm | 585mm | 8mm | 3mm | 15mm | 200mm |
7315-21, 7302-21 |
| 1142-1000A |
0-1000mm/0-40” |
±0.07mm | 1188mm | 10mm | 4mm | 18mm | 150mm |
7315-22, 7302-22 |
| 1142-10001A |
0-1000mm/0-40” |
±0.07mm | 1188mm | 10mm | 4mm | 18mm | 200mm |
7315-22, 7302-22 |
| 1142-10002A |
0-1000mm/0-40” |
±0.07mm | 1188mm | 10mm | 4mm | 18mm | 250mm |
7315-22, 7302-22 |
Sistema inalámbrico incorporado (receptor código 7315-2/3/6/7/8 es necesario)
|
CÓDIGO |
RANGO | PRECISIÓN | L | a | b | c |
d |
| 1142-150AWL |
0-150mm/0-6” |
±0.03mm | 230mm | 5mm | 2mm | 14.5mm |
100mm |
| 1142-200AWL |
0-200mm/0-8” |
±0.03mm | 280mm | 5mm | 2mm | 14.5mm |
100mm |
| 1142-300AWL |
0-300mm/0-12” |
±0.04mm | 380mm | 5mm | 2mm | 14.5mm |
150mm |
| 1142-500AWL |
0-500mm/0-20” |
±0.05mm | 585mm | 8mm | 3mm | 15mm |
150mm |
| 1142-5001AWL |
0-500mm/0-20” |
±0.05mm | 585mm | 8mm | 3mm | 15mm |
200mm |
